HST(For heavy duty)MT-30,MT-38,HT-30,HT-38,HT-42,HT-52

Features

Shoe type piston with high efficiency and durability
Neutral detent mechanism is optional appurtenances (some HSTs).
With mechanical / electric servo control (HT series)
Commonalized housing for fulfilling variations of displacement (MT-30 vs MT-38, HT-42 vs HT-52 etc.)

Specifications

	MT-30	MT-38	HT-30	HT-38	HT-42	HT-52
Piston Type	Shoe Type
Displacement(cc/min-1) Pump (Variable) Motor (Fixed)	0～30 30	0～38 38	0～30 30	0～38 38	0～42 42	0～52 52
Input Speed(min-1) Max. Min.	3,200 900
Intermittent operation pressure(MPa)	39.2	34.3	39.2	34.3	39.2
Recommended Charge Flow Rate(L/min)	more than 24				more than 26	more than 32
Port Size(Charge Suction)	G3/4
Port Size(Drain)	G1/2				G3/4
Control Shaft Operation	manual		electric servo control
Input/Output shaft size(mm)	25
Center Distance(mm)	105
Weight (Dry)(kg)	22		24		30
Recommended filter size (μm)	10
Oil	VG46 or SAE 10W-30 Class CD
Option
Relief Valve(MPa)	39.2	34.3	39.2	34.3	39.2
Charge Pump(cc/min-1)	8.2			11.8
Neutral Valve	Standard
Neutral detent mechanism	N/A or external detent		Standard
