HST(For light duty)KHS-13,KHS-18,KHS-23

Features

Shoe-less type piston.
Neutral detent mechanism is optional appurtenances (some HSTs).
Commonalized housing for fulfilling variations of displacement (KHS-18 vs KHS-23)
If the center distance of HST(light duty, mid duty and heavy duty) is same, they are compatible with each other.

Specifications

	KHS-13	KHS-18	KHS-23
Piston Type	Shoe-less Type
Displacement(cc/min-1) Pump (Variable) Motor (Fixed)	0～13 13	0～18 18	0～23 23
Input Speed(min-1) Max. Min.	3,200 900
Intermittent operation pressure(MPa)	14.7	24.5
Recommended Charge Flow Rate(L/min)	more than 6	more than 8
Port Size(Charge Suction)	G1/4
Port Size(Drain)	7/8-14UNF-2B	G3/8
Control Shaft Operation	manual
Input/Output shaft size(mm)	15	17
Center Distance(mm)	75	85
Weight (Dry)(kg)	7.5	13.5
Recommended filter size	10
Oil	VG46 or SAE 10W-30 Class CD
Option
Relief Valve(MPa)	－	24.5
Charge Pump(cc/min-1)	3	4
Neutral Valve	Standard
Neutral detent mechanism	N/A or external detent
